Microwave Coaxial Cable Assemblies
JUNFLON® MWX products are flexible signal transmission lines that take advantage of the remarkable properties of fluoropolymers. They are suitable for use with a wide range of frequencies up to 67 GHz.
These products feature low insertion loss and low VSWR, low signal leaks and low interference due to high shielding effectiveness, and higher density wiring for use in the narrow device interiors.
Junkosha provides highly reliable products for microwave/millimeterwave applications tailored to customer assembly needs.
MWX2 series: Flexible type for measurement
MWX2 series Cable assemblies developed in light of microwave/millimeterwave measurement environment, providing high phase stability and resistant to bending. (Suitable for extended use at temperatures ranging -30°C to +85°C)
Flexibility and low repulsion reduce load on measured objects.
Four cable types are available, depending on maximum usable frequency (26.5 GHz, 40 GHz, 50 GHz, and 67 GHz).
Major applications
- Microwave/millimeterwave measurements
- Micro-device measurements requiring high flexibility
Cable types
 |
| Link to another series |
 |
 |
 |
 |
 |
| Cable name | Maximum usable frequency |
|---|---|
| MWX221 | 26.5GHz |
| MWX241 | 40.0GHz |
| MWX251 | 50.0GHz |
| MWX261 | 67.0GHz |
Flexibility data
